  Page number:  JT-R01-030
DIFFERENTIAL ASSEMBLY
Call 877-771-3372 for current price & availability
Style Color
Code
OA/Thick OD/Deep ID/Wide Our Part Number Price Picture
Tooth Counts ID Marks
Year Miscellaneous Info
Years   Part Info Number
Call 877-771-3372 for current price & availability
37x9 teeth

9-1/4"

Natural

Black

JS
        JT-R01-03-003F-K5 Price Picture
not
available
R37 & L9 TZ102ZA1AA-JS
  Subaru 4x4
Top bolt centers = 8-5/16", 6 ribs under fill tube, Passenger drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, 9-1/4" threads to splines , 1-3/8" splines
Pump = 3 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x9 teeth

9-1/4"

Natural

E9
        JT-R01-03-0006-90 Price Picture
not
available
R37<A> & L9<B> T102ZW3AA-E9
  Subaru
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x9 teeth

9-1/4"

Turquoise

Gray

JS
VO       JT-R01-03-0002-AQ Price
R37<A> & L9<B> TZ102ZA1AA-JS
  Subaru 4x4
Bell = 8-5/16" top bolt centers, Push-in dipstick, Screw-in speedo, Passenger drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, 9-1/4" threads to splines
Pump = 3 bushings
Drive speedo = 25 teeth, Turquoise
Driven speedo = 20 teeth, Gray
Transfer gears = 53x53 teeth

    RING GEAR & PINION 38100AA250
37x9 teeth

9-1/4"

Turquoise

Turquoise

GI
RO       JT-R01-03-000W-E6 Price
R37 & L9 TZ102ZX3AA-GI
  Subaru 4x4
Bell = 8-5/16" top bolt centers, Push-in dipstick, Screw-in speedo, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, 9-1/4" threads to splines
Pump = 2 bushings
Drive speedo = 25 teeth, Turquoise
Driven speedo = 21 teeth, Turquoise
Transfer gears = 53x53 teeth

    RING GEAR & PINION 38100AA250
37x9 teeth

11-3/4"

Natural

Black

DR
        JT-R01-03-003X-8C Price Picture
not
available
R37 & L9 TZ102ZACAA-DR
  Subaru 4x4 2.2L
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, Threads to splines = 11-3/4", 1-1/4" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x9 teeth

11-3/4"

Natural

Black

GN
YER.YN       JT-R01-03-0035-A1 Price Picture
not
available
R37 & L9 TZ102ZA5AA-GN
  Subaru 4x4 2.2L
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, Threads to splines = 11-3/4", 1-1/4" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x9 teeth

12-3/4"

Natural

Black

C7
VRB.NN       JT-R01-03-0007-C2 Price
R37<A> & L9<B> TZ102ZAAAA-C7
  Subaru 4x4
Top bolt center = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, Threads to splines = 12-3/4", 1-3/8" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x9 teeth

12-3/4"

Natural

CL
        JT-R01-03-0016-A1 Price Picture
not
available
R37<A> & L9<B> TZ102ZABAA-CL
  Subaru, 4x4
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 37 teeth <A>
Pinion shaft = 9 teeth <B>, 12-3/4" threads to splines, 1-3/8" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x? teeth

9-1/4"

Natural
        JT-R01-03-0009-H6 Price Picture
not
available
R37 & L?
  Subaru
Top bolt centers = 7-5/8", ribs under fill tube, drain
Ring gear = 37 teeth <?>
Pinion shaft = teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = 23 teeth, Natural
Driven speedo = teeth,
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth

37x? teeth

9-1/4"

Natural
        JT-R01-03-000F-G2 Price Picture
not
available
R37 & L?
  Subaru
Top bolt centers = 7-5/8", ribs under fill tube, drain
Ring gear = 37 teeth <?>
Pinion shaft = teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = 23 teeth, Natural
Driven speedo = teeth,
Screw-in speedo
Screw-in dipstick
Transfer gear = ?? teeth

40x9 teeth

9-1/4"

Green
        JT-R01-03-000J-FA Price Picture
not
available
R40 & L9
  Subaru,
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 40 teeth <?>
Pinion shaft = 9 teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = 25 teeth, Green
Driven speedo = teeth,
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth

40x9 teeth

9-1/4"

Natural
        JT-R01-03-000L-KG Price Picture
not
available
R40 & L9
  Subaru,
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 40 teeth <?>
Pinion shaft = 9 teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = 23 teeth, Natural
Driven speedo = teeth,
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth

40x9 teeth

11-3/4"

Green

Green

DT
LY       JT-R01-03-000H-L6 Price
R40<A> & L9<BBB> TZ102Z2CBA-DT
  Subaru, 4x4
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 40 teeth <A-A>
Pinion shaft = 9 teeth <BBB>, Threads to splines = 11-3/4", 1-1/4" splines
Pump = 2 bushings
Drive speedo = 25 teeth, Green
Driven speedo = 19 teeth, Green
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

40x9 teeth

11-3/4"

Green

Green

KF
LR       JT-R01-03-001A-GR Price
R40<A-A> & L9<BBB> TZ102Z2DBA-KF
  Subaru 4x4 2.5L
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 40 teeth <A-A>
Pinion shaft = 9 teeth <BBB>, Splines = 11-3/4" to threads, 1-1/4" long
Pump = 2 bushings
Drive speedo = 25 teeth, Green
Driven speedo = 19 teeth, Green
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

40x9 teeth

11-3/4"

Green

Green

LI
LL       JT-R01-03-0012-CR Price
R40<A-A> & L9<BBB> TZ103ZJ1AA-LI
  Subaru, 4x4
Top bolt centers = 8-5/16", 4 ribs under fill tube, Center drain
Ring gear = 40 teeth <A-A>
Pinion shaft = 9 teeth <BBB>, Threads to splines = 11-3/4", 1-1/4" splines
Pump = 2 bushings
Drive speedo = 25 teeth, Green
Driven speedo = 19 teeth, Green
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

40x9 teeth

12-3/4"

Green

Green
        JT-R01-03-003K-LH Price Picture
not
available
R40<A-A> & L9<BBB>
  Subaru
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 40 teeth <A>
Pinion shaft = 9 teeth <BBB>, Threads to splines = 12-3/4", 1-3/8" splines
Pump = bushings
Drive speedo = 25 teeth, Green
Driven speedo = 25 teeth, Green
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

40x9 teeth

12-3/4"

Natural
        JT-R01-03-000Q-9T Price Picture
not
available
R40 & L9
  Subaru,
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 40 teeth <?>
Pinion shaft = 9 teeth <?>, Threads to splines = 12-3/4", 1-3/8" splines
Pump = bushings
Drive speedo = 23 teeth, Natural
Driven speedo = teeth,
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth

37x10 teeth

9-1/4"

Natural
        JT-R01-03-000G-J4 Price Picture
not
available
R37 & L10
  Subaru
Top bolt center = 7-5/8"
Ring gear = 37 teeth <?>
Pinion shaft = 10 teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Speedo drive = 23 teeth <?>
Screw in speedo
Push in dipstick
Transfer gear = ?? teeth

37x10 teeth

9-1/4"

Natural

Black

J3
VG       JT-R01-03-000V-A4 Price
R37 & L10 TA102AA1AA-J3
  Subaru Fwd
Top bolt centers = 8-5/16", 6 ribs under fill tube, Passenger drain
Ring gear = 37 teeth <>
Pinion shaft = 10 teeth <>, Threads to splines = 9-1/4"", 1-3/8" splines
Pump = bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

    RING GEAR & PINION 38100AA280
37x10 teeth

9-1/4"

Natural

Black

M6
LYL.YN       JT-R01-03-0004-GV Price
R37 & L10 TZ102AA1AA-M6
  Subaru Fwd
Top bolt centers = 8-5/16", 4 ribs under fill tube, Passenger drain
Ring gear = 37 teeth <>
Pinion shaft = 10 teeth <>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x10 teeth

9-1/4"

Natural

Black

NC
OO       JT-R01-03-0003-ET Price
R37 & L10 TZ102AA3AA-NC
  Subaru Fwd
Top bolt centers = 8-5/16", 4 ribs under fill tube, Passenger drain
Ring gear = 37 teeth <>
Pinion shaft = 10 teeth <>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = 2 bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

    RING GEAR & PINION 38100AA280
37x10 teeth

9-1/4"

None

None
        JT-R01-03-000N-PL Price Picture
not
available
R37 & L10
  Subaru
Top bolt centers = 8-5/16"
Ring gear = R37 <?>
Pinion shaft = L10 <?>, Threads to splines = 9-1/4", 1-3/8" splines
Speedo drive = NONE
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth

37x10 teeth

9-1/4"

Turquoise

Turquoise
        JT-R01-03-000M-MJ Price Picture
not
available
R37 & L10
  Subaru
Top bolt centers = 7-5/8"
Ring gear = 37 teeth < >
Pinion shaft = 10 teeth < >, Threads to splines = 9-1/4", 1-3/8" splines
Drive speedo = 25 teeth, Turquoise
Driven speedo = 21 teeth, Turquoise
Screw-in speedo
Push-in dipstick
Transfer gear = teeth

37x10 teeth

9-1/4"

Turquoise

Turquoise

J3
        JT-R01-03-003R-GY Price Picture
not
available
R37<> & L10<> TA102AA1AA-J3
  Subaru Fwd
Top bolt centers = 8-5/16", 6 ribs under fill tube, Passenger drain
Ring gear = 37 teeth <>
Pinion shaft = 10 teeth <>, 9-1/4" threads to splines, 1-3/8" splines
Pump = 3 bushings
Drive speedo = 25 teeth, Turquoise
Driven speedo = 21 teeth, Turquoise
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x10 teeth

9-1/4"

Turquoise

Turquoise

KI
        JT-R01-03-0021-AQ Price
R37 & L10 TZ102AM1AA-KI
  Subaru Fwd
Top bolt centers = 8-5/16"
Ring gear = 37 teeth <AA>
Pinion shaft = 10 teeth <B>, Threads to splines = 9-1/4", 1-3/8" splines
Drive speedo = 25 teeth, Turquoise
Driven speedo = 21 teeth, Turquoise
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

37x10 teeth

9-1/4"

Turquoise

Turquoise

LE
        JT-R01-03-000E-E0 Price Picture
not
available
R37 & L10
  Subaru 4x4
Top bolt centers = 7-5/8"
Ring gear = 37 teeth <A>
Pinion shaft = 10 teeth <B>, Threads to splines = 9-1/4", 1-3/8" splines
Speedo drive = 25 teeth, Turquoise
Driven speedo = 21 teeth, Turquoise
Screw-in speedo
Screw-in dipstick
Transfer gear = 47 teeth

39x10 teeth

9-1/4"

Natural

Black

4R
        JT-R01-03-001L-LH Price
R39 & L10 TZ102ZJ1AA-4R
  Subaru 4x4
Top bolt centers = 8-5/16", 6 ribs under fill tube, Passenger drain
Ring gear = 39 teeth <AA>
Pinion shaft = 10 teeth <BB>, Threads to splines = 9-1/4", 1-3/8" splines
3 pump bushings
Driven speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

39x10 teeth

9-1/4"

Natural

Black

MH
GO       JT-R01-03-0001-8N Price
R39 & L10 TZ102ZA2AA-MH
  Subaru 4x4
Top bolt center = 8-5/16", ribs under fill tube, Passenger drain
Ring gear = 39 teeth <AA>
Pinion shaft = 10 teeth <BB>, Threads to splines = 9-1/4", 1-3/8" splines
pump bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 19 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

39x10 teeth

9-1/4"

Natural

Black

ML
        JT-R01-03-002P-9T Price Picture
not
available
R39 & L10 TZ102ZJ2AA-ML
  Subaru 4x4
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 39 teeth <AA>
Pinion shaft = 10 teeth <BB>, Threads to splines = 9-1/4", 1-3/8" splines
pump bushings
Drive speedo = 23 teeth, Natural
Driven speedo = 16 teeth, Black
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

39x10 teeth

9-1/4"

Turquoise

Turquoise
        JT-R01-03-000X-G8 Price Picture
not
available
R39 & L10
  Subaru
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 39 teeth <?>
Pinion shaft = 10 teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = 25 teeth, Turquoise
Driven speedo = teeth, Turquoise
Screw-in speedo
Push-in dipstick
Transfer gear = ? teeth

39x11 teeth

9-1/4"
        JT-R01-03-000K-HE Price Picture
not
available
R39 & L11
  Subaru
Top bolt center = 8-5/16"
Ring gear = 39 teeth <?>
Pinion shaft = 11 teeth <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = 25 teeth <?>
Screw in speedo
Push in dipstick
Transfer gear = teeth
Probably SVX only (some K codes)

39x11 teeth

9-1/4"

KP
        JT-R01-03-0013-FU Price Picture
not
available
R39<A> & L11<> TZ102ZM1AA-KP
  Subaru 4x4
Top bolt centers = 8-5/16", , drain
Ring gear = 39 teeth <A>
Pinion shaft = 11 teeth <>, 9-1/4" threads to splines, 1-3/8" splines
Pump = bushings
Drive speedo = 25 teeth, Turquoise
Driven speedo = 20 teeth, Gray
Screw-in speedo
Push-in dipstick
Transfer gear = 53 teeth

39x11 teeth

12-3/4"

K7

4x4
        JT-R01-03-0038-J7 Price Picture
not
available
  TZ102ZM3AA-K7
96 Subaru 4x4
Top bolt center = 8-5/16"
Ring gear = 39 teeth <A>
Pinion shaft = 11 teeth <B>, Nut near pump, Splines near nut, 12-3/4" splines to nut
Speedo drive = 25 teeth, Turquoise
Speedo driven = 20 teeth, Natural
Screw in speedo
Push in dipstick
Transfer gear = 53 teeth
Centered drain plug

39x?? teeth         JT-R01-03-0008-F4 Price Picture
not
available
R39 & L?
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut near pump
Spline near nut
Nut to nut = 15" (Longest)
1-3/8" splines
Speedo drive = L23 <?>
Screw in speedo
Screw in dipstick
Transfer gear = ?? teeth

39x?? teeth         JT-R01-03-000A-FQ Price Picture
not
available
R39 & L?
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = 25T <?>
Screw in speedo
Screw in dipstick
Transfer gear = ?? teeth

39x?? teeth         JT-R01-03-000C-KV Price Picture
not
available
R39 & L?
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = 23T <?>
Screw in speedo
Push in dipstick
Transfer gear = ?? teeth

39x?? teeth         JT-R01-03-000Y-7A Price Picture
not
available
R39 & L??
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = L25 <?>
Screw in speedo
Screw in dipstick
Transfer gear = ? teeth

39x?? teeth         JT-R01-03-0010-JM Price Picture
not
available
R39 & L??
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = L23 <?>
Screw in speedo
Screw in dipstick
Transfer gear = ? teeth

39x?? teeth         JT-R01-03-0011-9P Price Picture
not
available
R39 & L??
  Subaru
Top bolt center = 7-5/8"
Ring gear = R39 <?>
Pinion shaft = L? <?>
Nut away pump
Spline near nut
Nut to nut = 11-1/4" (Shortest)
1-3/8" splines
Speedo drive = L23 <STEEL>
Screw in speedo
Push in dipstick
Transfer gear = ? teeth

40x10 teeth

9-1/4"

NONE

NONE
        JT-R01-03-000P-7Q Price Picture
not
available
R40 & L10
  Subaru,
Top bolt centers = 8-5/16", ribs under fill tube, drain
Ring gear = 40 teeth <?>
Pinion shaft = 10 teeth <?>, Threads to splines = 9-1/4", 1-3/8" splines
Pump = bushings
Drive speedo = NONE
Driven speedo = NONE
Screw-in speedo
Push-in dipstick
Transfer gear = ?? teeth


Payment 877-771-3372 More parts 877-771-3372 Contact


Unless otherwise indicated, all parts are USED

We have millions of used transmission parts in stock. If we don't list the part you need, please contact us.


We would like to keep this website ad-free. If you find this site useful, a small donation would be appreciated. Please click here for more information.

Transmission parts for the masses
877-771-3372

All content copyright 1984-2019 by mmerlinn.


Honesty counter
Free counters provided by Honesty.com


  Last updated:  06/25/2019
